Ranges:
Waveforms
Outputs
Connectors
Dimensions
- 0.2 Hz to 5 MHz in seven ranges (±1 count)
- 0.5 Hz to 5 MHz in seven ranges (±1 count)
Waveforms
- Sine: distortion < 1% (below 100kHz;
- Sine: distortion < 3% (at 1 kHz)
- Square: 2% symmetry, 50 nS max rise and fall time
- Symmetry: 0.5 Hz to 100 kHz = 2% Rise time: = 120 ns
- Triangle: 98% linearity below 100 kHz, 95% above 100 kHz
- Linearity: 98% to 100 kHz, 95% to 2 MHz
Outputs
- 20 V p-p no load
- 10 V p-p max into 50 Ohm load - continuously variable
- 20 dB range with 20 dB step - DC offset: ±10 V (no load)
- ±5 V (50 Ohm load) - TTL/CMOS-compatible pulse
Connectors
- BNC to insulated alligator clips
Dimensions
- 114 x 298 x 264 mm
-
Pedir Cotización
Peso Bruto: 5,77 kg
NOTA IMPORTANTE:
Debido a regulaciones aduaneras locales nos resulta imposible comercializar este equipo en territorio Argentino.
